Max Pressure: < 100 Psi
Type: Digital
Certification: CE
Voltage: 12 Vol
Place of Origin: Guangdong China (Mainl)
Br Name: carsfm
Model Number: TY02
Warranty: 1 Years
product: TPMS
Wk frequence: 433.92Mhz
Sensitivity: 115dbm
Sens Battery life: ≥2 year
Sens Operating Temp: -20℃~+60℃
Pressure Range: 0~3.5 Bar
Warranty: 1 year
Static Current: ≤1 uA
Model: 4 sens
Battery Life: 2 year
1. What are the advantages of TPMS ?
lReduce Driving Risks
lImprove Fuel Economy
lProlong lifetime of the tires
2. Features:
Easy installation and reliable
Clear and large display
Solar power supported
Build in with rechargeable lithium battery
Automatic waking up when vehicle start in motion
Automatic backlight on/off for daytime or nighttime
High pressure and low pressure setting by user
High temperature setting by user
Visual and audible alerts for high/low pressure, high temperature and fast leakage
Pressure unit selectable: PSI, BAR
Able to read up to 5 tires
Automatic pair sensor with tyre location, no need to input sensor ID
3. Specifications:
Monitor specifications:
|
Operating voltage: |
12 to 24V |
|
Frequency |
433.92MHz |
|
Operating temperature |
-40 to +85° C |
|
Size |
90x 60 x 23 mm |
|
Weight |
120g |
Internal Sensor Specifications:
|
Pressure range: |
0 to 8 bar, 0 to 116psi |
|
Pressure sensitivity: |
± 0.1 bar or 1.5psi |
|
Temperature sensitivity: |
± 3℃ |
|
Transmission power: |
< 10dBm |
|
Transmission frequency: |
433.92MHz |
|
Battery life: |
5 years |
|
Operating temperature: |
-40 to +125° C |
|
Weight: |
48grams |
|
Size: |
60*31*20mm(L*W*H) |
